Air Conditioner Copper Aluminum Pipe

1.Aluminum copper pipe including one set air conditioner insulated copper pipe, size, and other accessories, like communication wire cable, drain hose 3m, wall pipe and cover and the other necessary parts.
2.Both of the two ends are copper pipe, length is 15cm. The rest is Pure Aluminum Pipe, 1000series 1070 grade aluminum. Soft aluminum pipe easy to be bend to be flexible.
3. PVC platic pipe is coverd whole aluminum pipe, to protect the aluminum pipe not to be wet, keep the good qualiy.
4. For the AC Installation kit, most popular size is 3m 4m and 5m. Europe want 6m 7m 8m 10m.
5. For the insulation we have SGS test report including ASTM E 84, UL 94, ASTM D1056, ASTM G 21, and copper pipe meets ASTM B280 AND C12200.
6.Professional manufacturer of Mini Split Installation Kit, 2 factories, 1,000,000PCS per month, 5days for sample and 14years' experience.
  • DBJ-003

  • DABUND

  • Copper

  • 1M - 10M

Material:
Color:
Keywords:
Application:
Availability:
Quantity:

HVAC Parts are produced by Dabund Pipe since 2008 years.

In the Heating, including Air Conditioner Copper Aluminum Pipe, wall pipe with cover and drain hose, wire cable. Get free sample on qualified Mini split air conditioner kit Venting & Cooling System.


Key Features of Air Conditioner Copper Aluminum Pipe

1.Aluminum copper pipe Kit including one set air conditioner insulated copper pipe, size 3/8"+3/4" 15 ft, and other accessories, like communication wire cable, drain hose 3m, wall pipe and cover and the other necessary parts.

2.Both of the two ends are copper pipe, length is 15cm. The rest is Pure Aluminum Pipe, 1000series 1070 grade aluminum. Soft aluminum pipe easy to be bend to be flexible.

3. PVC platic pipe is coverd whole aluminum pipe, to protect the aluminum pipe not to be wet, keep the good qualiy.

4. For the AC Installation kit, most popular size is 3m 4m and 5m. Europe want 6m 7m 8m 10m.

5. For the insulation we have SGS test report including ASTM E 84, UL 94, ASTM D1056, ASTM G 21, and copper pipe meets ASTM B280 AND C12200.

6.Professional manufacturer of Mini Split Installation Kit, 2 factories, 1,000,000PCS per month, 5days for sample and 14years' experience.


Aluminum Tube: 99% pure Aluminum

Copper Tube: ASTM B280 & C12200 DHP

Insulation: High density closed cells polyethylene foam

Working Temperature: meets/exceeds ASTM C 1427-07

Surface burning characteristics: UL 94, top-rated for Surface Burning Characteristics – UL 723 Flame and Spread Index less than 25 and Smoke Development Index less than 50

Meets ASTM E84 for smoke and fire (25/50)

Superior tear resistance, UV resistant



AC aluminum pipe5

Aluminum pipe

AC aluminum pipe8

Aluminum Copper pipe welding

AC aluminum pipe7

Aluminim Copper pipe


Insulation pipe has white embossed insulation pipe and black rubber pipe

white PE insulation pipe

White PE embossed insulated pipe

black rubber insulation pipe

Rubber insulated pipe


Features of white embossed insulation pipe:

OUTER LAYER-Anti-aging, UV-resistant PE fllm, wear-resistant embossed pattern, antl-aging.

MIDDLE LAYER-IXPE foam, dense cell, heat and cold-resistant, impact absorption, no water penetration, good thermal insulation. Water cross-linked PE foam.

INNER LAYER-Closed-cell structure, air tightness; good thermal insulation, temperature resistant -40℃~120℃.


Features of rubber insulation pipe:

Pipe Insulation, Material Polyethylene, Pre-Slit, Temp. Range -160 Degrees to 200 Degrees .

The pipe insulation has a better function of moisture condensation. Insulation material is both the insulation layer and moisture-proof layer.

There is no need to drop the water vapor permeation protective layer so that it has a better moisture condensation function.

The pipe insulation tubing is made of rubber and plastic which holds very tight and you do not feel tired when oprate it.


Whiet PE insulated copper and aluminum pipe


black rubber copper Aluminum pipe


Air Conditioner Copper Aluminum Pipe for HVACR Applications Wholesaler & Supplier

DABUND PIPE in-house tested Aluminum Copper Pipe is designed to make installation sample and quick – saving you time and money on each job.




Aluminum Copper Pipe

Size

Length

Insulation Black Rubber

Flame Resistant

1/4+3/8
3m/4m/5m/7m/10m
8mm/9mm/10mm/13mm/19mm/25.4mm
M1/B1
1/4+1/2
3m/4m/5m/7m/10m
8mm/9mm/10mm/13mm/19mm/25.4mm
M1/B1
1/4+5/8
3m/4m/5m/7m/10m
8mm/9mm/10mm/13mm/19mm/25.4mm
M1/B1
3/8+5/8
3m/4m/5m/7m/10m
8mm/9mm/10mm/13mm/19mm/25.4mm
M1/B1
3/8+3/4
3m/4m/5m/7m/10m
8mm/9mm/10mm/13mm/19mm/25.4mm
M1/B1
1/2+3/4
3m/4m/5m/7m/10m
8mm/9mm/10mm/13mm/19mm/25.4mm
M1/B1
3/8+7/8
3m/4m/5m/7m/10m
8mm/9mm/10mm/13mm/19mm/25.4mm
M1/B1


1/4 + 3/8 Aluminum copper pipe kit used for 0.75TON - 1.0TON mini split air conditioner.

1/4 + 1/2 Insulated aluminum&copper line set used for 1.5TON - 2.0TON mini split air conditioning.

1/4 + 5/8 Insulated aluminum&copper piping used for 2.0TON - 2.5TON split air conditioner system.

3/8 + 5/8 Insulated aluminum&copper tube apply for 3.0TON - 4.0TON ductless mini split air conditioner.

3/8 + 3/4 Insulated aluminum&copper tubing used for 4.5TON - 6.0TON split air conditioner installation.

3/8 + 7/8 Insulated aluminum&copper piping apply for 6.0TON - 8.0TON ductless mini split air conditioner.


Air conditioning aluminum&copper line sets 1/4 + 3/8 used for 0.75P and 1P split air conditioning.

Copper&aluminum pipe kit 1/4 + 1/2 commonly used for 1.5P and 2P mini split air conditioners.

1/4 + 5/8 Mini Split Air Conditioner Kit used for 2P and 2.5air conditioner system.

3/8 + 5/8 Mini-split copper&aluminum line set apply for 3P and 4P ductless mini split air conditioner.

3/8 + 3/4 Copper&aluminum pipe kit used for 4.5P and 6P split aircon installation.

3/8 + 7/8 Aluminum&copper pipe kit apply for 6P - 8p TON ductless mini split air conditioner.


1/4 + 3/8 Mini split line set used for 9000BTU and 12000 BTU split air conditioner.

Copper&aluminum line set 1/4 + 1/2 commonly used for 12000 BTU and 18000 BTU mini split air conditioners.

1/4 + 5/8 Insulated copper&aluminum line set used for 24000 BTU and 30000 BTU air conditioner system.

3/8 + 5/8 Mini-split line set apply for 36000 BTU and 48000 ductless air conditioner.

3/8 + 3/4 Aluminum copper pipe kit used for 54000 BTU and 72000 split air conditioner installation.

3/8 + 7/8 Mini split air conditioner kit apply for 72000 BTU - 96000 BTU ductless mini split air conditioner.


Aircon copper line set 1/4 + 3/8 used for 9K and 12K split air conditioner.

High quality copper&aluminum line set 1/4 + 1/2 commonly used for 12K and 18K mini split air conditioners.

1/4 + 5/8 Insulated copper&aluminum line set used for 24K and 30K air conditioner system.

3/8 + 5/8 Aluminum&copper pipe kit apply for 36K and 48K ductless air conditioner.

3/8 + 3/4 Mini split air conditioner kit used for 54K and 72K split air conditioner installation.

3/8 + 7/8 Mini split air conditioner kit apply for 72K - 96K ductless mini split air conditioner.



Why Choose Air Conditioner Copper Aluminum Pipe from DABUND PIPE

We are manufacturer of Air Conditioner Copper Aluminum Pipe since 2008 years, have good experience of producing and exporting. We have cooperated 9 years forwarder, can guarantee the shipment. Every week we load at least 6-8 40HQ to different countries. Choose Dabund You will win the business.

Individual pre-insulated rolls to perfectly fit every ductless mini-splits, VRF, heat pumps and unitary systems installation.


Quality products with competitive pricing

Peace of mind with professional services




DABUND FACTORY


We produce Insulated Copper Pipe, Mini Split Line Set and Aluminum Pipe and HVAC Parts


DABUND PIPE COPPER AND ALUMINUM PIPE



SGS Certificate


Mini Split Line Set is made of Polypropylene or Black Rubber with UV Resistant, meets ASTM E 84, UL94, ASTM D1056 and ASTM G 21


证书



Exhibition


We join the exhibitions all over the word, just to facilitate customers to experience our mini split line set face to face.


Exhibition


FAQ

1.Q:What is your payment terms?

A:TT,L/C AT SIGHT,CREDIT CARD etc


2.Q:What is your delivery terms?

A:EXW, FOB, CFR, CIF etc


3.Q:Are you trading company or manufacturer?

A:Manufacturer


4.Q:May I get a sample?

A:Yes, we can send you 3pieces free samples.

   You just charge for the express cost is ok.


5.Q:Can I print my logo?

A:Yes of cause, we accept OEM and ODM.


6.Q:How long is your delivery time?

A:Usually 15-20days, if urgent, we can arrange to do in advance and delivery fast.
