75 ft 1/4″ × 3/8″ Mini Split Line Set Installation Kit – Pre-Insulated HVAC Copper Tubing

75 ft 1/4" x 3/8" Mini Split Line Set Installation Kit

The 75 ft 1/4" x 3/8" mini split line set installation kit is a long pre-insulated HVAC copper refrigerant tubing solution designed for ductless mini split air conditioners, heat pumps, residential HVAC systems and light commercial installations.

This line set includes 1/4" liquid line and 3/8" suction line copper tubing with factory-applied insulation. It helps support reliable refrigerant flow, reduce energy loss, control condensation and simplify extended HVAC line runs between indoor and outdoor units.

With a 75 ft length, this mini split line set is suitable for projects where the outdoor condenser must be installed farther from the indoor unit. Final line length, refrigerant charge and compatibility should always follow the HVAC equipment manufacturer’s installation manual.

Complete Mini Split Line Set Installation Kit

This all-in-one mini split line set installation kit is designed for clean, professional and efficient HVAC installation. The pre-insulated copper refrigerant lines help reduce field preparation and support long-distance indoor-to-outdoor unit connections.

• 75 ft pre-insulated copper refrigerant lines.

• 1/4" liquid line and 3/8" suction line.

• Pre-flared ends with flare nuts for faster connection.

• High-density insulation to reduce heat transfer and condensation.

• Protective packaging for secure transport and storage.

• Suitable for extended HVAC line runs and flexible condenser placement.

Technical Specifications

Premium HVAC Copper Refrigerant Tubing

The line set is manufactured with 99.9% pure seamless copper tubing for reliable refrigerant transfer, thermal conductivity and corrosion resistance. Copper is widely used in HVAC refrigerant lines because it supports stable pressure performance and long service life.

1/4" Liquid Line

The 1/4" copper tube is commonly used as the liquid line, carrying high-pressure refrigerant from the outdoor condenser toward the indoor evaporator coil.

3/8" Suction Line

The 3/8" copper tube is commonly used as the suction line, returning low-pressure refrigerant vapor from the indoor unit back to the outdoor compressor.

High-Quality Pre-Insulation Features

Factory-applied insulation helps maintain refrigerant temperature, reduce unwanted heat transfer and minimize condensation. It also protects the copper line set from outdoor exposure and installation damage.

• Closed-cell insulation helps reduce moisture absorption.

• UV and moisture-resistant outer jacket options are available.

• Helps reduce condensation and energy loss.

• Improves cooling and heating efficiency in different climates.

• Supports stable line set performance in long HVAC runs.

99.9% Pure Copper

Black Rubber Insulated Pipe

Plastic Cap Protection

Features of Black Rubber Pipe Insulation

Black rubber insulation is designed for HVAC refrigerant line protection. It supports thermal insulation, moisture resistance and condensation control for mini split and heat pump installations.

• Temperature range from -40℃ to 120℃.

• Moisture condensation protection for copper refrigerant lines.

• Insulation material works as both insulation layer and moisture-proof layer.

• No additional water vapor barrier is required in many normal installations.

• Suitable for indoor and outdoor HVAC line set installation.

Key Benefits of This Mini Split Line Set

Ideal for Residential and Light Commercial Installations

This 75 ft mini split line set is suitable for ductless mini split air conditioners and heat pump systems in homes, apartments, offices and light commercial spaces.

Faster Installation Saves Time and Labor

Pre-flared ends and factory-applied insulation help reduce on-site preparation time. Installers can route and connect the refrigerant lines more efficiently compared with field-insulated copper tubing.

Longer Runs for Flexible HVAC Layouts

At 75 ft, this long line set supports extended refrigerant runs and gives installers more flexibility when placing the outdoor condenser away from the indoor unit.

Applications: Where This 75 ft Line Set Is Used

This 75 ft 1/4" x 3/8" mini split line set is used in HVAC projects that require a longer refrigerant line distance between indoor and outdoor units.

• Residential ductless AC systems.

• Ductless heat pump installations.

• Multi-zone mini split systems.

• Light commercial HVAC projects.

• Retrofit or replacement refrigerant line projects.

• Longer line runs for flexible condenser placement.

HVAC Installation Best Practices

Measure the Required Line Run Before Installation

Measure the full distance between indoor and outdoor units before installation. Confirm that 75 ft is within the HVAC equipment manufacturer’s allowed line length and refrigerant charge requirements.

Verify Continuous Insulation Coverage

Check that insulation remains continuous along the full run, especially near wall penetrations, bends, support points and outdoor exposed sections.

Properly Torque Flare Nuts

Use proper torque values according to the HVAC equipment manual. Correct flare connection and sealing help prevent refrigerant leakage.

Avoid Sharp Bends and Kinks

Avoid sharp bends that may restrict refrigerant flow or damage the insulation. Use suitable bending tools and secure the line set with proper supports.

Mini Split Line Set Size Options

Recommended Applications by AC Capacity

The 1/4" x 3/8" line set is commonly used for 0.75 ton to 1.0 ton mini split systems and many 9,000 BTU to 12,000 BTU applications. Final line set size should always follow the HVAC equipment manufacturer’s requirements.

Why Choose 75 ft 1/4" x 3/8" Mini Split Line Set from Dabund Pipe?

Manufacturer Since 2008

Dabund Pipe is a manufacturer of mini split line sets, insulated copper pipe, aluminum pipe and HVAC parts with long-term production and export experience.

Individual Pre-Insulated Rolls

Individual pre-insulated rolls are designed to fit ductless mini splits, VRF systems, heat pumps and unitary HVAC system installations.

Competitive B2B Supply

Dabund supports HVAC distributors, contractors and private-label buyers with quality products, competitive pricing, OEM customization and professional service.

Dabund Factory

Dabund produces insulated copper pipe, mini split line set, aluminum pipe and HVAC parts for global customers.

SGS Certificate

Mini split line set insulation can be made of polypropylene or black rubber with UV resistance, meeting ASTM E84, UL94, ASTM D1056 and ASTM G21 requirements.

Exhibition

Dabund joins HVAC exhibitions worldwide to present mini split line set and HVAC installation products to customers face to face.

FAQ

What is a 75 ft 1/4" x 3/8" mini split line set used for?

It is used to connect indoor and outdoor units in ductless mini split air conditioners, heat pumps and HVAC systems where a longer 75 ft refrigerant line run is required.

What does 1/4" x 3/8" mean?

It refers to the outer diameters of the copper refrigerant lines. The 1/4" line is generally used as the liquid line, and the 3/8" line is generally used as the suction line.

What AC capacity is this line set commonly used for?

This 1/4" x 3/8" line set is commonly used for 0.75 ton to 1.0 ton mini split systems, including many 9,000 BTU to 12,000 BTU units.

Is this 75 ft line set compatible with all mini split brands?

It is compatible with many mini split and ductless HVAC systems in the US and international markets. Always check the equipment manufacturer’s line size, maximum length and refrigerant charge requirements before installation.

Can this line set be shortened if needed?

Yes. The copper tubing can be cut to fit specific project lengths, but proper cutting, deburring, flaring and sealing techniques must be used to maintain system integrity.

Is additional insulation required?

In most normal installations, additional wrapping is not required because the line set comes with factory-applied insulation. Exposed outdoor areas may still benefit from a protective line set cover.

Are the pipe ends pre-flared?

Yes. The copper pipes can be supplied with pre-flared ends and flare nuts to help reduce installation time and improve connection consistency.

Is this line set suitable for R410A and R32 refrigerants?

Yes. This mini split line set can be used with common HVAC refrigerants such as R410A and R32 when installed according to system specifications and local HVAC code requirements.

Can Dabund provide other sizes and lengths?

Yes. Dabund can provide multiple line set sizes and lengths, including 15 m, 20 m, 25 m, 30 m and 50 m, with different insulation thickness options.

Are you a trading company or manufacturer?

Dabund is a manufacturer of mini split line sets, insulated copper pipe, aluminum pipe and HVAC parts.

Can I get a free sample?

Yes. Dabund can provide qualified customers with 3 pieces of free samples. Express cost may need to be covered by the buyer. You can request samples through the free sample page.

Can I print my logo?

Yes. Dabund accepts OEM and ODM orders, including logo printing, brand marking and customized packaging.

What payment terms are available?

Payment terms may include T/T, L/C at sight, credit card and other agreed payment methods depending on order details.

What delivery terms can you offer?

Dabund can offer common international trade terms such as EXW, FOB, CFR and CIF.

How long is your delivery time?

Normal delivery time is usually 15 to 20 days. For urgent orders, production and shipment can be arranged in advance according to factory schedule.
