DBJ-003
-
DABUND
-
Copper
-
1M - 50M
-
1/4,3/8,1/2,5/8,3/4,7/8,1,1-1/8
Material
Color
Keywords
Application
Optimized for US residential and commercial HVAC installations, this pre-insulated copper pipe meets ASTM standards and supports modern refrigerants like R410A and R32.
The Insulated Copper Pipe is twin already. So buy it now.
Product Overview – Long-Length Insulated Copper Line Set
This 100 ft 1/2″ × 3/4″ insulated copper pipe combines high-purity copper tubes with factory-applied insulation for outstanding thermal efficiency, reduced condensation, and easier installation. Perfect for long runs between indoor and outdoor units in HVAC and refrigeration systems.
Extended 100 ft Length for Flexible Installations
Ideal for long distance runs in residential, commercial, and industrial HVAC installs
Eliminates the need for extra couplers and joins
Great for rooftop units, multi-story setups, and wide spacing between components
Standard 1/2″ × 3/4″ Refrigerant Line Size
1/2″ (12.70 mm) liquid refrigerant tube
3/4″ (19.05 mm) suction return tube
Common configuration for many split air conditioners and ductless systems
Factory-Applied Insulation – Thermal & Moisture Protection
Enhanced Thermal Efficiency
The factory insulation jacket minimizes heat gain/loss along the line set, improving HVAC system efficiency and helping maintain optimum refrigerant temperature during operation.
Condensation & Moisture Control
Pre-insulated tubing significantly reduces surface condensation and sweating, protecting surrounding surfaces such as walls, ceilings, and structural components.
UV-Resistant & Durable for Outdoor Exposure
The insulation material (polypropylene/closed-cell foam) is UV-resistant and designed to withstand outdoor conditions, providing long-lasting protection in varied climates.
Premium Construction for HVAC Reliability
99.9% Pure Copper Tubing
Made with high-purity copper, delivering excellent thermal conductivity and corrosion resistance
Meets industry standards ASTM B280 and C12200 for HVAC refrigerant lines
Designed for High-Pressure HVAC Use
This copper pipe supports pressures far exceeding typical HVAC requirements, ensuring reliable performance across cooling and heating cycles.
HVAC Compatibility & Applications
Works with Mini Split, Ductless & Central AC Systems
This insulated copper tubing is suitable for:
Mini split air conditioner installations
Ductless heat pump systems
Centralized air conditioning units
Residential and commercial HVAC applications
Compatible with Common Refrigerants
Designed for use with popular HVAC refrigerants such as R410A, R32, and other industry-standard refrigerants meeting typical operating pressures.
99.9% Pure Copper
White PE Insulated Pipe
Plastic Cap
Features of pipe insulation tubing:
Machines for the production of thermal insulation pipes
warehouse for insulation pipes
Inner Layer Insulated Pipe
Key Benefits of This Insulated Copper Pipe
Simplifies Installation & Saves Time
Factory-applied insulation eliminates the need for field insulation wrapping, reducing installation time, labor, and the risk of insulation errors.
Improves HVAC Energy Efficiency
By maintaining stable refrigerant temperatures along long runs, this pipe helps your system operate more efficiently, potentially lowering energy consumption.
Reduces Condensation & Structural Moisture Issues
Pre-insulation significantly reduces surface sweating, protecting interiors and structures from water damage and moisture buildup.
Technical Specifications
| Feature | Value |
|---|---|
| Length | 100 ft (30.48 m) |
| Liquid Line Size | 1/2″ (12.70 mm) |
| Suction Line Size | 3/4″ (19.05 mm) |
| Material | 99.9% Pure Copper |
| Insulation Type | Factory-applied, UV-resistant |
| Temperature Range | -40 °C to 120 °C |
| Applications | Mini split, ductless & central HVAC |
| Standards | ASTM B280, C12200 |
| Pressure Rating | 2100 – 7000 PSI (exceeds R410 requirements) |
Installation Tips for Best Results
Plan Your Line Route Carefully
Before installation, measure the total distance and plot the routing to avoid sharp bends that might constrain refrigerant flow or damage insulation.
Protect Tubing at Wall Penetrations
Use wall sleeves or grommets where the tubing passes through walls to prevent insulation abrasion and ensure a neat finish.
Support Long Runs With Proper Clamps
Use HVAC line clamps or brackets to secure the pipe along its length, minimizing vibration and maintaining insulation integrity.
Insulated Copper Pipe
Size | Length | Insulation White PE | Flame Resistant |
1/4+3/8 | 15m/20m/25m/30m/50m | 8mm/9mm/10mm/13mm/19mm/25.4mm | M1/B1 |
1/4+1/2 | 15m/20m/25m/30m/50m | 8mm/9mm/10mm/13mm/19mm/25.4mm | M1/B1 |
1/4+5/8 | 15m/20m/25m/30m/50m | 8mm/9mm/10mm/13mm/19mm/25.4mm | M1/B1 |
3/8+5/8 | 15m/20m/25m/30m/50m | 8mm/9mm/10mm/13mm/19mm/25.4mm | M1/B1 |
3/8+3/4 | 15m/20m/25m/30m/50m | 8mm/9mm/10mm/13mm/19mm/25.4mm | M1/B1 |
1/2+3/4 | 15m/20m/25m/30m/50m | 8mm/9mm/10mm/13mm/19mm/25.4mm | M1/B1 |
3/8+7/8 | 15m/20m/25m/30m/50m | 8mm/9mm/10mm/13mm/19mm/25.4mm | M1/B1 |
1/4 + 3/8 Insulated copper pipe used for 0.75TON - 1.0TON mini split air conditioner.
1/4 + 1/2 Mini split line set used for 1.5TON - 2.0TON mini split air conditioning.
1/4 + 5/8 Copper line set used for 2.0TON - 2.5TON split air conditioner system.
3/8 + 5/8 Insulated copper tube apply for 3.0TON - 4.0TON ductless mini split air conditioner.
3/8 + 3/4 Insulated copper tubing used for 4.5TON - 6.0TON split air conditioner installation.
3/8 + 7/8 Insulated copper piping apply for 6.0TON - 8.0TON ductless mini split air conditioner.
Air conditioning copper line sets 1/4 + 3/8 used for 0.75P and 1P split air conditioning.
Copper pipe kit 1/4 + 1/2 commonly used for 1.5P and 2P mini split air conditioners.
1/4 + 5/8 Insulated copper line set used for 2P and 2.5air conditioner system.
3/8 + 5/8 Mini-split copper line set apply for 3P and 4P ductless mini split air conditioner.
3/8 + 3/4 Copper pipe kit used for 4.5P and 6P split aircon installation.
3/8 + 7/8 Insulated copper pipe apply for 6P - 8p TON ductless mini split air conditioner.
1/4 + 3/8 Mini split line set used for 9000BTU and 12000 BTU split air conditioner.
All copper line set 1/4 + 1/2 commonly used for 12000 BTU and 18000 BTU mini split air conditioners.
1/4 + 5/8 Insulated copper line set used for 24000 BTU and 30000 BTU air conditioner system.
3/8 + 5/8 Mini-split line set apply for 36000 BTU and 48000 ductless air conditioner.
3/8 + 3/4 Insulated copper pipe used for 54000 BTU and 72000 split air conditioner installation.
3/8 + 7/8 Insulated copper pipe apply for 72000 BTU - 96000 BTU ductless mini split air conditioner.
Aircon copper line set 1/4 + 3/8 used for 9K and 12K split air conditioner.
High quality copper line set 1/4 + 1/2 commonly used for 12K and 18K mini split air conditioners.
1/4 + 5/8 Insulated copper line set used for 24K and 30K air conditioner system.
3/8 + 5/8 Mini-split line set apply for 36K and 48K ductless air conditioner.
3/8 + 3/4 Insulated copper pipe used for 54K and 72K split air conditioner installation.
3/8 + 7/8 Insulated copper pipe apply for 72K - 96K ductless mini split air conditioner.
Why Choose This 100 ft Insulated Copper Pipe
Extended Run Capability With Superior Protection
The long 100 ft length accommodates distant indoor/outdoor setups while preventing heat loss and condensation over extended refrigerant runs.
High-Quality Materials for Reliable HVAC Performance
With 99.9% pure copper and industry-rated insulation, this pipe delivers durability, thermal efficiency, and long-term reliability.
Ideal for Residential & Commercial HVAC Projects
Whether you’re a professional HVAC installer or an experienced DIYer, this insulated copper pipe supports efficient performance across diverse applications.
DABUND FACTORY
We produce Insulated Copper Pipe, Mini Split Line Set and Aluminum Pipe and HVAC Parts
SGS Certificate
Mini Split Line Set is made of Polypropylene or Black Rubber with UV Resistant, meets ASTM E 84, UL94, ASTM D1056 and ASTM G 21
Exhibition
We join the exhibitions all over the word, just to facilitate customers to experience our mini split line set face to face.
FAQ
1.Q:What is your payment terms?
A:TT,L/C AT SIGHT,CREDIT CARD etc
2.Q:What is your delivery terms?
A:EXW, FOB, CFR, CIF etc
3.Q:Are you trading company or manufacturer?
A:Manufacturer
4.Q:May I get a sample?
A:Yes, we can send you 3pieces free samples.
You just charge for the express cost is ok.
5.Q:Can I print my logo?
A:Yes of cause, we accept OEM and ODM.
6.Q:How long is your delivery time?
A:Usually 15-20days, if urgent, we can arrange to do in advance and delivery fast.
7.What does “1/2″ × 3/4″” mean?
It describes the outer diameters of the refrigerant tubes — 1/2″ for the liquid line and 3/4″ for the suction line — a common configuration for mini split and split HVAC systems.
8.Is this insulated pipe suitable for outdoor HVAC use?
Yes — the factory insulation is UV-resistant and designed for both indoor and outdoor refrigerant line runs.
9.Do I need additional insulation on site?
No — this product includes factory-applied insulation that eliminates the need for extra field wrapping in most installations.
10.Can this pipe handle modern refrigerants like R410A?
Yes — this insulated copper tubing is compatible with R410A, R32, and similar refrigerants, and supports pressure levels beyond typical HVAC requirements.
