1.Insulated Copper Pipe including one set air conditioner insulated copper tube, size 1/4"+3/8" 35 ft, and other accessories, like communication wire cable, drain hose 3m, wall pipe and cover and the other necessary parts.
2. Both of the two copper pipe end do flaring and nuts.
3. The insulation we can offer White PE and Black Rubber. White PE thickness is 3/8" 1/2" 3/4" 1" or 8mm 9mm 10mm 13mm 19mm 25.4mm. Black Rubber thickness is 1/2" 3/4" 1" or 13mm 17mm 19mm 25.4mm.
4. For the Insulated Copper Pipe, most popular size is 3m 4m and 5m. Europe want 6m 7m 8m 10m.
5. For the insulation we have SGS test report including ASTM E 84, UL 94, ASTM D1056, ASTM G 21, and copper pipe meets ASTM B280 AND C12200.
6.Professional manufacturer of Insulated Copper Tube, 2 factories, 1,000,000PCS per month, 5days for sample and 14years' experience.
  • DBJ-003

  • DABUND

  • Copper

  • 1M - 10M

Material

99.9% pure copper

Color

Black/White

Keywords

Insulated Copper Tube

Application

HVAC
Inquire
Add to Basket

35 ft 1/4 in. x 3/8 in. Insulated Copper Tube

DABUND 35 ft 1/4 in. x 3/8 in. Insulated Copper Tube is a pre-insulated refrigerant line set designed for compatible ductless mini split air conditioners, heat pumps, residential HVAC systems and refrigeration applications.

The twin copper line combines a 1/4 in. liquid line with a 3/8 in. suction line and provides a 35 ft length, approximately 10.6 m, for common residential and light commercial HVAC installations.

Manufactured from 99.9% pure copper with ASTM B280 / C12200 referenced in the source product information, the tubing is factory insulated and supplied with pre-flared ends and nuts for professional HVAC installation.

Quick Answer: This 35 ft 1/4 x 3/8 mini split line set combines high-purity copper, pre-flared connections and factory-applied insulation for compatible mini split and HVAC systems.

35 ft Mini Split Line Set Video

35 ft 1/4 x 3/8 Line Set Specifications

Product TypePre-Insulated Copper Refrigerant Line Set
Pipe Size1/4 in. + 3/8 in.
Liquid Line1/4 in. / 6.35 mm
Suction Line3/8 in. / 9.52 mm
Length35 ft / approximately 10.6 m
Copper Material99.9% Pure Copper
Copper StandardASTM B280 / C12200
ConnectionPre-Flared Ends with Nuts
Featured InsulationBlack Rubber
Other Available InsulationWhite PE is also referenced as an available option
Listed Temperature Range-40°C to 120°C for the listed Black Rubber insulation configuration
ApplicationsCompatible Mini Split / Heat Pump / HVAC / Refrigeration Systems

What Is an Insulated Copper Tube Line Set?

An insulated copper line set is a paired refrigerant piping assembly used to connect compatible indoor and outdoor HVAC equipment.

This product combines a smaller 1/4 in. liquid refrigerant line with a larger 3/8 in. suction line and factory-applied thermal insulation.

Factory insulation helps reduce unwanted heat transfer and surface condensation around refrigerant tubing during compatible HVAC operation.

35 ft Length for Mini Split Installations

The 35 ft / 10.6 m length provides additional routing flexibility compared with shorter line sets while remaining suitable for many compatible residential and light commercial installations.

Before installation, measure the complete route between indoor and outdoor units and verify that the equipment manufacturer permits the required refrigerant piping length.

1/4 in. Liquid Line and 3/8 in. Suction Line

This line set uses a 1/4 in. liquid line and a 3/8 in. suction return line.

Buyers should verify that the selected mini split or heat-pump system specifically requires these exact copper tube diameters.

Nominal BTU or tonnage should only be used as an initial reference because pipe-size requirements can vary between HVAC manufacturers and individual equipment models.

99.9% Pure Copper with ASTM B280 / C12200

The source product information specifies 99.9% pure copper and references ASTM B280 and C12200 for professional HVAC refrigerant piping applications.

Copper provides thermal conductivity, corrosion resistance and flexibility for routing compatible refrigerant piping.

Pre-Flared Copper Ends with Nuts

Both copper tubes are described as having pre-flared ends with nuts, reducing the amount of field flaring required when the supplied connections match the HVAC equipment.

Installers should inspect every flare before assembly and tighten flare nuts according to the HVAC equipment manufacturer's specified torque requirements.

Black Rubber Insulated Copper Tube

The featured product images and wider family table show Black Rubber insulation around the copper refrigerant tubing.

Black Rubber insulation acts as both a thermal layer and a moisture-resistant barrier, helping reduce condensation around cold refrigerant piping.

The source product information lists a temperature range of approximately -40°C to 120°C for the Black Rubber insulation configuration.

Copper Line Set and Insulation Video

99.9 percent pure copper mini split refrigerant tubing

99.9% Pure Copper

Black Rubber insulated copper mini split line set

Black Rubber Insulated Pipe

pre-flared copper connection for mini split line set

Pre-Flared Connection

Black Rubber Insulation Structure

The insulation functions as both a thermal barrier and moisture-resistant layer around the copper refrigerant pipe.

Its closed-cell structure helps reduce water-vapor penetration and condensation during compatible HVAC operation.

Black Rubber closed-cell insulation for mini split copper pipe

White PE or Black Rubber Insulation Options

The source page states that both White PE and Black Rubber insulation options are available.

Buyers should confirm the required insulation material, thickness, color, flame-resistance requirement and outdoor exposure conditions before ordering.

Compatible Mini Split and HVAC Applications

  • Compatible ductless mini split air conditioners

  • Heat-pump systems

  • Residential HVAC installations

  • Small commercial cooling systems

  • Compatible refrigeration systems

Final compatibility should be confirmed from the HVAC equipment manufacturer's required liquid-line size, suction-line size, refrigerant type and permitted piping length.

General 9,000–12,000 BTU Capacity Reference

The wider DABUND product family lists 1/4 in. + 3/8 in. as a general reference for some 0.75–1.0 ton or 9,000–12,000 BTU mini split systems.

This is a general reference only. Final line-set sizing must follow the equipment manufacturer's exact technical specification.

Complete Mini Split Installation Kit Option

The source page states that this line set can also be supplied as part of a complete mini split installation kit.

  • Insulated copper line set

  • Communication cable

  • Drain hose

  • Wall sleeve or wall pipe cover

The exact accessory list can vary by configuration, so buyers should confirm wire specification, drain-hose length and wall-sleeve components before ordering.

35 ft Black Rubber mini split copper pipe installation kit

Available Insulated Copper Tube Sizes

SizeAvailable LengthsBlack Rubber InsulationListed Flame-Resistance Options
1/4 + 3/8 in.3 m / 4 m / 5 m / 7 m / 10 m8 / 9 / 10 / 13 / 19 / 25.4 mmM1 / B1
1/4 + 1/2 in.3 m / 4 m / 5 m / 7 m / 10 m8 / 9 / 10 / 13 / 19 / 25.4 mmM1 / B1
1/4 + 5/8 in.3 m / 4 m / 5 m / 7 m / 10 m8 / 9 / 10 / 13 / 19 / 25.4 mmM1 / B1
3/8 + 5/8 in.3 m / 4 m / 5 m / 7 m / 10 m8 / 9 / 10 / 13 / 19 / 25.4 mmM1 / B1
3/8 + 3/4 in.3 m / 4 m / 5 m / 7 m / 10 m8 / 9 / 10 / 13 / 19 / 25.4 mmM1 / B1
1/2 + 3/4 in.3 m / 4 m / 5 m / 7 m / 10 m8 / 9 / 10 / 13 / 19 / 25.4 mmM1 / B1
3/8 + 7/8 in.3 m / 4 m / 5 m / 7 m / 10 m8 / 9 / 10 / 13 / 19 / 25.4 mmM1 / B1

Length Note: This specific product is 35 ft / approximately 10.6 m. The wider product-family table lists up to 10 m as a standard family length, so buyers should specify the exact finished 35 ft configuration when ordering.

General Line Set Size and Capacity Reference

Line Set SizeGeneral Ton ReferenceGeneral BTU Reference
1/4 + 3/8 in.0.75–1.0 Ton9,000–12,000 BTU
1/4 + 1/2 in.1.5–2.0 Ton12,000–18,000 BTU
1/4 + 5/8 in.2.0–2.5 Ton24,000–30,000 BTU
3/8 + 5/8 in.3.0–4.0 Ton36,000–48,000 BTU
3/8 + 3/4 in.4.5–6.0 Ton54,000–72,000 BTU
3/8 + 7/8 in.6.0–8.0 Ton72,000–96,000 BTU

These capacity ranges are general product-family references only. Final line-set sizing must follow the HVAC equipment manufacturer's exact pipe-size requirements.

OEM and Customization Services

  • White or Black insulation options

  • Custom insulation thickness

  • Logo printing on insulation

  • Custom production lengths

  • Custom packaging

  • OEM and ODM manufacturing

These options are intended for HVAC wholesalers, distributors, contractors and brand owners requiring customized line-set configurations.

DABUND HVAC Supply Capability

The source page states that DABUND supplies insulated copper pipe, mini split line sets and other HVAC products to international customers and supports bulk production and OEM requirements.

DABUND insulated copper line set supply and logistics

Insulation Test Documentation

The source certificate section states that applicable Polypropylene or Black Rubber insulation configurations reference ASTM E84, UL94, ASTM D1056 and ASTM G21.

Because insulation configuration can vary between White PE and Black Rubber products, buyers requiring project-specific compliance documents should confirm the exact material, thickness and corresponding test report for the ordered SKU.

DABUND mini split line set insulation test documentation

International HVAC Exhibitions

DABUND participates in HVAC exhibitions where professional buyers can review insulated copper tubing, mini split line sets and related HVAC products.

DABUND mini split line sets at HVAC exhibition

Frequently Asked Questions

What is a 35 ft 1/4 x 3/8 insulated copper line set used for?

It is used as refrigerant piping between compatible indoor and outdoor mini split, heat-pump or HVAC equipment requiring a 1/4 in. liquid line and 3/8 in. suction line.

How long is this line set?

The product is 35 ft long, approximately 10.6 m.

What size mini split can use a 1/4 x 3/8 line set?

The wider DABUND product family lists 1/4 x 3/8 as a general reference for some 0.75–1.0 ton or 9,000–12,000 BTU systems. Final sizing must follow the equipment manufacturer's exact requirements.

Is the copper tubing pre-flared?

Yes. The source product information states that both copper tube ends are pre-flared and supplied with nuts.

What copper material is used?

The source product information specifies 99.9% pure copper and references ASTM B280 / C12200.

What insulation is used?

The source page lists White PE and Black Rubber as available insulation options. The current product images and family table prominently show Black Rubber insulation.

What insulation thicknesses are available?

The wider Black Rubber product family lists 8 mm, 9 mm, 10 mm, 13 mm, 19 mm and 25.4 mm insulation thicknesses.

What is the listed temperature range?

The Black Rubber insulation description lists approximately -40°C to 120°C.

Is this line set compatible with R410A?

R410A is referenced in the source FAQ. Final compatibility must still be confirmed against the equipment manufacturer's tubing, pressure and refrigerant requirements.

Is the line set suitable for outdoor installation?

The source page describes available insulation as UV resistant. Final outdoor suitability should be confirmed for the exact insulation material, thickness and exposure conditions.

Does this product include a complete installation kit?

A complete installation-kit configuration is available according to the source page and may include communication cable, drain hose and a wall pipe cover. Confirm the actual accessory list before ordering.

Can the 35 ft copper tubing be shortened?

The tubing can be shortened when suitable HVAC cutting, deburring and flaring procedures are used according to the equipment manufacturer's requirements.

Can DABUND customize the product?

Yes. The source page lists custom insulation color, insulation thickness, line-set length, logo printing and packaging as OEM and ODM options.

Should this line set be installed by an HVAC professional?

Refrigerant piping connections, evacuation, leak testing and refrigerant charging should follow the equipment manufacturer's installation procedure and applicable local requirements. Professional HVAC installation is recommended.
